Professional High Tension Stringing Block for OPGW Installation with 5-20KN Rated Load

1 piezas
MOQ
negotiable
Precio
Professional High Tension Stringing Block for OPGW Installation with 5-20KN Rated Load
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Nombre: Desviar el bloque de encordado hacia el cielo
Modelo: El número de personas
Aplicable: LGJ25-400
Carga nominal: 5-20KN
peso: 1,7-3,8 kg
Garantía: 1 año
Información básica
Lugar de origen: Ningbó
Nombre de la marca: Suntech
Certificación: ISO
Número de modelo: El número de personas
Pago y Envío Términos
Detalles de empaquetado: Caja de madera contrachapada
Tiempo de entrega: 3-7 días
Condiciones de pago: LC, T/T
Capacidad de la fuente: 3000 unidades/mes
Descripción de producto
Professional Swerve Skyward Stringing Block for High Tension Overhead Conductor and OPGW Installation
The Swerve Skyward Stringing Block is a heavy-duty, professional-grade installation tool specifically engineered for the demanding challenges of modern overhead power line construction. It is a critical component in tension stringing systems designed to safely and efficiently install conductors, Optical Ground Wire (OPGW), and other cables.
Product Specifications
Item Number Model Rated Load (KN) Dia×Width Applicable Conductor ACSR Weight (kg) Remark
10231 SHC-0.5 5 Φ80X50 25-185 1.5 Aluminium sheave
10232 SHC-2 20 φ120X60 35-240 3
10221 SHC-1 10 ≤ 400 4
10233 SHCN-0.5 5 Φ80X50 25-185 1.1 Nylon sheave
10234 SHCN-2 20 φ120X60 35-240 2.3
10222 SHLN-1 10 ≤ 400 3
Key Features & Benefits
Minimizes Friction for Efficient High-Tension Pulls: Large-diameter sheave and high-quality bearings drastically reduce rolling resistance, enabling longer continuous pulls with precise cable tension control.
Provides Unmatched Protection for Sensitive Cables: Smooth, contoured groove cradles cables without damaging point loads, especially critical for OPGW and fiber optic cable protection.
Essential for Modern High-Capacity Transmission Lines: Supports large-diameter conductors, bundled configurations, and extreme tensions of extra-high-voltage (EHV) lines.
Engineered for Extreme Durability and Long Service Life: Corrosion-resistant aluminum alloys and sealed bearings withstand harsh field conditions for reliable performance.
Enhances Crew Safety During Critical Operations: Prevents sudden cable snags and derailments, creating a safer environment during high-tension stringing operations.
Specifically Optimized for OPGW Installation: Meticulously designed to protect delicate glass fibers within OPGW cables, preventing signal attenuation.
Improves Project Efficiency and Lowers Costs: Faster pulling speeds, reduced fuel consumption, and superior cable protection eliminate expensive rework.
Professional Grade for Utility Contractors: Demonstrates commitment to industry best practices and technical capability for complex power line projects.
Supports Resilient Power Grid Development: Contributes to building more reliable transmission infrastructure capable of handling peak demands and severe weather.
Strategic Investment in Construction Capability: Protects multi-million-dollar cable assets while ensuring personnel safety and minimizing project risks.
The Swerve Skyward Stringing Block is a precision-engineered solution that balances robust durability with friction-reducing performance to protect valuable assets, enhance safety, and drive efficiency. It is an indispensable tool for professionals building and maintaining high-voltage networks, ensuring projects are completed to the highest standards of quality, reliability, and longevity.
